H2C
Induction hotend with automatic swap and 330 × 320 × 325 mm
1/7Choose your version
Bambu Lab builds each model in several versions. This is the one we stock and what we bring to order.
Official name: H2C AMS Combo / Standard
- H2C printer with Vortek automatic hotend changer
- One AMS 2 Pro
Official name: H2C Laser Full Combo / 10W Laser
- H2C with 455 nm blue diode laser module, 10 W ±1 W
- AMS 2 Pro and engraving accessories
Official name: H2C Laser Full Combo / 40W Laser
- H2C with 455 nm blue diode laser module, 40 W ±2 W
- AMS 2 Pro and engraving accessories
Official name: H2C Vortek Ultimate Bundle / Standard
- H2C printer
- Full set of Vortek hotends for the automatic changer
H2 platform variant with an induction right hotend and a rack that swaps hotends automatically. Shares its volume and plates with the A2L. For multi-material production where every nozzle swaps itself.
- Induction hotend on the right side with an automatic hotend swap station.
- 330 × 320 × 325 mm, same plates as the A2L.
- H2 platform: heated chamber, linear rail on X and filtering.
- 300 × 285 mm blade cutting area.
What matters
Vortek: cambia el hotend, no purga
Sistema inteligente que reemplaza el hotend completo durante el cambio de material. Impresión multimaterial mas rápida y limpia con el mínimo desperdicio.
Hasta 24 materiales en una impresión
Integración total con el AMS: no hay que cargar filamento a mano en el cabezal. Un algoritmo de asignación reparte filamentos y hotends para reducir desperdicio.
Mapeo inteligente de filamento
Cada hotend guarda en su memoria la información del filamento. Con mas de siete tipos de filamento el sistema calcula la combinación óptima para minimizar la purga.
Hotend dedicado a materiales de ingeniería
Se puede reservar uno de los seis hotends para un filamento concreto (PA6-CF, PAHT-CF, PC FR) y ganar consistencia y fiabilidad en materiales costosos.
Official Bambu Lab video
Meet Vortek: multi-material with zero purge waste
H2C creations: multi-material in action
Specifications
Printing
| Build volume | 330 × 320 × 325 mm |
|---|---|
| Single nozzle build volume | 325 × 320 × 325 mm |
| Materials per print | up to 24 |
Toolhead and extrusion
| Left hotend | conventional FAH023, hardened steel 0.4 mm |
|---|---|
| Right hotend | induction FAH051 (0.4 mm) with heating assembly FAC191 and latch FAC192 |
| Hotend rack | FAC190 station with belt, 3513 motor, control board and latch actuator: automatic swap |
| Extruder | dual extruder unit FAE044 |
| Max nozzle temperature | 350 °C |
Chamber and structure
| Structure | enclosed CoreXY of the H2 platform, linear rail on X |
|---|---|
| Chamber heating | PTC heater (FAC118 on 110 V, FAC119 on 220 V), active exhaust |
| Blade cutting area | 300 × 285 mm; drawing 300 × 255 mm |
Electronics and connectivity
| TH board | DLB060 with DLB061 connection board; the MC has an extra connector for the hotend hanger |
|---|---|
| Plate detection | separates type and alignment; a slight offset triggers an error |
Compatibility
AMS
AMS 2 Pro and AMS HT (tube FAT010, buffer SA009). Filament Track Switch planned for 2026 according to Bambu Lab. Does not use AMS lite.
Build plates
- Textured PEI Plate FAP035
- Engineering Plate FAP039
- Cool Plate SuperTack FAP041
- Same plates as the A2L (330 × 320 mm)
Hotends and nozzles
- Left: FAH023 and the H2 line (FAH024, FAH025, FAH026, high flow FAH030 to FAH032, tungsten FAH039 to FAH045)
- Right (induction): FAH050 stainless 0.2 mm, FAH051 / FAH052 / FAH053 hardened steel 0.4 / 0.6 / 0.8 mm, FAH054 / FAH055 / FAH056 high flow
- FAH066 H2C hotend combo
Materials
Prints
- Those of the H2 platform: PLA, PETG, ABS, ASA, PC, nylon and fiber filaments
With care
- PPS-CF and PPA-CF do not run through the AMS
Versus its siblings
| H2D | Induction right hotend with automatic swap rack; additional connector on the MC; stricter plate alignment detection. |
|---|---|
| A2L | Same volume and same plates (330 × 320 × 325 mm); the H2C is enclosed with a heated chamber and dual hotend, the A2L is open. |
Good to know
- Strict plate alignment detection: a slight plate offset stops the job.
- Filament Track Switch not yet available for the H2C (planned for 2026).
Frequently asked questions
What changes versus the H2D?
The right hotend is induction and sits in a rack that swaps it automatically. The left one is the same FAH023 as the H2D.
Does it use the same plates as the A2L?
Yes, exactly the same: 330 × 320 mm.
Can I use filament from other brands?
Yes. The printer and the AMS accept third-party spools. RFID reading and remaining filament estimation only work with Bambu Lab spools. A Bambu spool measures 200 mm in diameter, 55 mm core and 67 mm wide; a spool from another brand must fit those dimensions to go inside the AMS.
What warranty does NODEM give?
NODEM gives a 30 day warranty and records the serial number of the unit at the time of sale. That serial number identifies the machine to the service workshop and to Bambu Lab.
Can I get spare parts?
Yes. Every part has an official Bambu Lab SKU code and NODEM orders it by that code. The NODEM service guide lists the frequent cases and the spare parts for this model.
Warranty and service
Bambu Lab factory warranty: we review each case and handle it as an authorized distributor. We give a 30-day warranty for factory defects from the sale, with the serial number on the invoice.
Original parts by official part number and our own workshop in Maracaibo.
